TABEL BERAT
Berat karet lembaran (NR, NBR, EPDM, VITON) | Weight of rubber sheet
TABEL BERAT FLANGE JIS 5K 10K 16K 20K
TABEL BERAT BUTTERFLY VALVE CAST IRON
TABEL BERAT BUTTERFLY VALVE | TABEL BERAT WAFER CHECK VALVE | TABEL BERAT KNIFE GATE VALVE | TABEL BERAT GLOBE VALVE | TABEL BERAT GATE VALVE | TABEL BERAT CHECK VALVE | TABEL BERAT BALL VALVE.
TABEL BERAT BUTTERFLY VALVE CAST IRON Download
| SIZE | WEIGHT (KG) | ||
|---|---|---|---|
| INC | MM | LEVER | GEAR |
| 2" | 50 | 4.4 | 7.9 |
| 2,5" | 65 | 5.2 | 8.7 |
| 3" | 80 | 5.7 | 9.2 |
| 4" | 100 | 7.4 | 10.9 |
| 5" | 125 | 10.2 | 13.7 |
| 6" | 150 | 11.1 | 14.6 |
| 8" | 200 | 15.5 | 26.5 |
| 10" | 250 | 26.5 | 36.8 |
| 12" | 300 | 35 | 48 |
| 14" | 350 | - | 60 |
| 16" | 400 | - | 92 |
| 18" | 450 | - | 118.8 |
Jika anda sedang mencari atau membutuhkan butterfly valve cast iron silahkan hubungi kami, kami mensuplly merk merk seperti Tozen, yone, HQ, Riser, Kitz, Toyo, Gala, Dll
 |
| PIC BUTTERFLY VALVE TOZEN MODEL GEAR |
TABEL BERAT GLOBE VALVE DAN GATE VALVE CLASS #800
TABEL BERAT GLOBE VALVE DAN GATE VALVE CLASS #800
TABEL BERAT GATE VALVE | TABEL BERAT CHECK VALVE | TABEL BERAT BALL VALVE | TABEL BERAT BUTTERFLY VALVE | TABEL BERAT WAFER CHECK VALVE | TABEL BERAT KNIFE GATE VALVE.
Standards
Class 800
Bolted bonnet
Rising stem
NACE MR-0175
Basic Design API 602
Socket Weld ANSI 16.11
Threaded ANSI B1.20.1
Test API 598
Threaded or socket weld
TABEL BERAT GATE VALVE | TABEL BERAT CHECK VALVE | TABEL BERAT BALL VALVE | TABEL BERAT BUTTERFLY VALVE | TABEL BERAT WAFER CHECK VALVE | TABEL BERAT KNIFE GATE VALVE.
 |
| Pic Gate Valve Cl #800 |
Class 800
Bolted bonnet
Rising stem
NACE MR-0175
Basic Design API 602
Socket Weld ANSI 16.11
Threaded ANSI B1.20.1
Test API 598
Threaded or socket weld
| Tabel Berat Valve A105 Forged Carbon Steel Class 800 | ||||
|---|---|---|---|---|
| Size | GATE VALVE | GLOBE VALVE | ||
| Inch | 800# | 1500# | 800# | 1500# |
| 1/2" | 2,1 | 3,8 | 2 | 3,3 |
| 3/4" | 3,6 | 5,4 | 3,3 | 5,5 |
| 1" | 5,3 | 8 | 5,4 | 9 |
| 1 1/2" | 9,8 | 15 | 10,8 | 18 |
| 2" | 15 | 19 | 19 | 22 |
| Equivalent : Npt/Sw/Bw | ||||
Jika nada sedang mencari valve dengan spesifikasi di atas silahkan hubungi kami, harga kompetitif bisa di kirim ke luar kota.
DOWNLOAD TABLE BERAT GATE VALVE
TABEL BERAT GATE VALVE | TABEL BERAT CHECK VALVE | TABEL BERAT BALL VALVE | TABEL BERAT BUTTERFLY VALVE | TABEL BERAT WAFER CHECK VALVE |
Jika info ini bermanfa'at silahkan share ke rekan anda agar lebih bermanfa'at
Jangan lupa like FB kami
| TABEL BERAT GATE VALVE API 600 ASTM A216 WCB | ||||||
|---|---|---|---|---|---|---|
| Size | Class #150 | Class #300 | Class #600 | Class #900 | Class #1500 | Class #2500 |
| Inch | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs |
| 2" | 18 | 24 | 46 | 95 | 82 | 135 |
| 2.1/2" | 28 | 44 | 55 | 108 | 127 | 210 |
| 3" | 34 | 52 | 72 | 125 | 168 | 271 |
| 4" | 52 | 76 | 754 | 192 | 277 | 506 |
| 5" | 71 | 94 | 253 | - | - | - |
| 6" | 88 | 146 | 413 | 378 | 640 | 1571 |
| 8" | 144 | 218 | 623 | 635 | 1180 | 2401 |
| 10" | 197 | 352 | 981 | 900 | 2118 | 4520 |
| 12" | 298 | 472 | 1316 | 1550 | 3244 | - |
| 14" | 406 | 694 | 1672 | 2170 | 3693 | - |
| 16" | 524 | 1080 | 2070 | 3070 | 4890 | - |
| 18" | 720 | 1235 | 2405 | 3930 | - | - |
| 20" | 1117 | 1655 | 4550 | 5120 | - | - |
| 24" | 1466 | 2320 | 5260 | 7800 | - | - |
| 26* | 1699 | 3100 | 5960 | - | - | - |
| 28* | 1931 | 3893 | 6700 | - | - | - |
| 30* | 2380 | 4930 | 8312 | - | - | - |
| 32* | 2490 | 5230 | 10125 | - | - | - |
| 36* | 3600 | 6885 | - | - | - | - |
| 42* | 4710 | - | - | - | - | - |
| 48* | 6500 | - | - | - | - | - |
Jika info ini bermanfa'at silahkan share ke rekan anda agar lebih bermanfa'at
Jangan lupa like FB kami
TABEL BERAT SWING CHECK VALVE A216 WCB
TABEL BERAT SWING CHECK VALVE A216 WCB
Dear All
Karena banyak yang minta tabel berat untuk Swing check valve besi Berikut kami postingkan tabelnya, semoga bisa membantu.
 |
| Check Valve A216 Wcb |
Karena banyak yang minta tabel berat untuk Swing check valve besi Berikut kami postingkan tabelnya, semoga bisa membantu.
| Standard materials of parts | |
|---|---|
| Parts | Materials |
| Body | ASTM A216 Gr.WCB |
| Cover | A105/ASTM A216 Gr.WCB |
| Disc | ASTM A182 Gr.F6a (11/2?? ~ 6??) |
| ASTM A216 Gr.WCB + 13Cr | |
| (8" & larger) | |
| Disc nut | ASTM A194 Gr.8 |
| Body seat ring | ASTM A182 Gr.F6a |
| Cover bolt / nut | ASTM A193 Gr.B7/A194 Gr.2H |
| Arm | ASTM A105 (11/2?? ~ 14??) |
| ASTM A216 Gr.WCB (16?? & larger) | |
| Gasket | See Page 7. |
| Plug | ASTM A576 Gr.1045 |
| Tabel Berat Swing Check Valves A216 WCB | |||||
|---|---|---|---|---|---|
| SIZE | CLASS #150 | CLASS #300 | CLASS #600 | CLASS #900 | CLASS #1500 |
| INCH | BERAT/KG | BERAT/KG | BERAT/KG | BERAT/KG | BERAT/KG |
| 2 | 19 | 21 | 52 | 69 | 69 |
| 2.5 | 26 | 32 | 63 | 93 | 93 |
| 3 | 29 | 43 | 75 | 85 | 140 |
| 4 | 48 | 61 | 122 | 145 | 232 |
| 5 | 69 | 84 | - | - | - |
| 6 | 77 | 131 | 227 | 310 | 490 |
| 8 | 133 | 213 | 346 | 500 | 990 |
| 10 | 266 | 384 | 628 | 772 | 1490 |
| 12 | 347 | 449 | 796 | 1080 | 1970 |
| 14 | 451 | 680 | 892 | 1500 | 2450 |
| 16 | 556 | 840 | 1200 | 2130 | 3205 |
| 18 | 784 | 1025 | 1600 | - | - |
| 20 | 835 | 1320 | 2420 | - | - |
| 24 | 1580 | 1960 | 3150 | - | - |
| 30 | 2120 | 3270 | 1960 | - | - |
| 36 | 3344 | - | 3270 | - | - |
TABEL BERAT COUPLING CLASS 3000 CS A105
TABEL BERAT COUPLING CLASS 3000 CS A105
TABEL BERAT COUPLING CLASS 3000 CS A105 SOCKET WELD, TABEL BERAT COUPLING CLASS 3000 CS A105 NPT, TABEL BERAT COUPLING CLASS 6000 CS A105 SOCKET WELD, TABEL BERAT COUPLING CLASS 6000 CS A105 NPT.
TABEL BERAT COUPLING CLASS 3000 CS A105 SOCKET WELD, TABEL BERAT COUPLING CLASS 3000 CS A105 NPT, TABEL BERAT COUPLING CLASS 6000 CS A105 SOCKET WELD, TABEL BERAT COUPLING CLASS 6000 CS A105 NPT.
| Couplings Class 3000 A105 CS | ||||
|---|---|---|---|---|
| DN SIZE |
|
|
||
| kg | Lb | kg | Lb | |
| 1/2 | 0,13 | 0,280 | 0,13 | 0,290 |
| 3/4 | 0,17 | 0,40 | 0,19 | 0,42 |
| 1 | 0,29 | 0,65 | 0,45 | 0,83 |
| 1 1/4 | 0,45 | 1,05 | 0,81 | 1,58 |
| 1 1/2 | 0,59 | 1,23 | 1,07 | 2,16 |
| 2 | 0,86 | 2,05 | 1,40 | 2,99 |
| 2 1/2 | 1,40 | 3,12 | 2,29 | 4,75 |
| 3 | 1,78 | 3,83 | 3,38 | 6,51 |
